Bot Detection in a Cloudflare Worker: What the Edge Can and Cannot See

A Cloudflare Worker runs before your origin does, in a datacenter near the visitor, with the connection metadata already parsed. That makes it the cheapest place on the internet to answer some questions and a structurally impossible place to answer others. Getting the split right is most of the design work.

This covers what the edge sees for free, what it cannot see, and a Worker that sends the full Maskbreak check for a form post in front of your origin, in the three steps the Maskbreak console lists: add the script to the page with your form, send the check from your server (here, the Worker), and submit your form once. It starts in watch mode, where every check is logged and nothing is refused.

What you get for free

Every request into a Worker arrives with a cf object and a set of headers that cost nothing to read:

export default {
  async fetch(request, env, ctx) {
    const ip      = request.headers.get('CF-Connecting-IP');
    const country = request.headers.get('CF-IPCountry');   // ISO-2, or XX / T1
    const cf      = request.cf || {};
    // cf.asn, cf.asOrganization, cf.colo, cf.tlsVersion, cf.clientTcpRtt,
    // cf.botManagement.score  (Enterprise entitlement only)
    // ...
  }
};

Two traps in that snippet. CF-IPCountry is not always a country: Cloudflare emits T1 for Tor and XX when it has no idea, and both render as a broken flag if you pass them to a flag component. And cf.botManagement is only populated with the Enterprise Bot Management entitlement; on other plans the property is absent, so code that reads cf.botManagement.score throws rather than degrading.

What the edge structurally cannot see

A Worker sees a connection. It does not see a browser. Nothing in request.cf tells you whether the client is an antidetect profile with a spoofed canvas, a headless Chrome instance, an emulator, or a person. Those are properties of the runtime on the other end, and they only become visible when something running in that runtime reports them.

This is also why the edge cannot answer the residential proxy question on its own. A residential proxy exits through a real consumer connection: the ASN is a real ISP, the country is real, the TCP round trip looks like a home line. There is nothing anomalous in the connection metadata, because the connection is genuinely ordinary.

So the useful division is:

• At the edge, before origin: known-bad networks, datacenter ASNs, Tor exits, obvious automation by user agent, and rate limiting. Cheap, no round trip, no cost to your origin.
• At the action, with the browser's evidence: device signals (automation, emulator, antidetect browser, browser tampering), multi-account linking, and the VPN and proxy reading of the visitor's own connection. These need the browser to have spoken.

Edge triage on facts you already have

The first pattern needs no API: act at the edge, before the request reaches your application, on the connection facts.

const DATACENTER_ASNS = new Set([16509, 14618, 15169, 8075, 14061, 16276]);

export default {
  async fetch(request, env, ctx) {
    const url = new URL(request.url);
    // Only guard what is worth guarding. Everything else passes through.
    if (!url.pathname.startsWith('/signup')) return fetch(request);

    const cf = request.cf || {};
    if (DATACENTER_ASNS.has(cf.asn)) {
      // Friction, not a verdict: mark it for stricter handling downstream.
      const marked = new Request(request);
      marked.headers.set('X-Edge-Datacenter', '1');
      return fetch(marked);
    }
    return fetch(request);
  }
};

Be careful how hard you lean on that list. A datacenter ASN is a fact about infrastructure, not a verdict about a person: corporate VPNs, mobile carrier gateways and privacy relays all live in ranges that look like hosting. Refusing signup outright on ASN alone costs real users. It is a reasonable trigger for a challenge or stricter downstream handling, and a poor trigger for a 403. If your origin reads a header like that one, make sure only the Worker can set it.

Step 1: Add the script to the page with your form

The full check needs evidence from the visitor's browser. On the page that holds the form, load the script and put class="monocle-enriched" on the <form> element itself (never on an input):

<script async src="https://maskbreak.com/assets/sentinel.js"></script>

<form class="monocle-enriched" method="post" action="/signup">
  <input type="email" name="email" required>
  <button type="submit">Create account</button>
</form>

The script adds three hidden fields to that form: monocle (the network token), sentinel_fp (the browser check id) and sentinel_tz (the time zone). A JavaScript frontend calls await window.Sentinel.collect() instead (check that window.Sentinel exists, and submit anyway when it does not) and sends its token, fingerprintEventId and tz in a JSON body; the Worker below reads both. If the page sends a Content-Security-Policy, add https://maskbreak.com, https://mcl.maskbreak.com, https://*.mcl.maskbreak.com, https://mesu.maskbreak.com and 'wasm-unsafe-eval' to script-src, the mcl hosts (https and wss) and mesu to connect-src, and https://mesu.maskbreak.com blob: to worker-src.

Step 2: Send the check from your server (the Worker)

The Worker reads the posted body once, sends the check, and forwards the original request to your origin. It sends whatever evidence arrived, including none: a check without a token or a browser check id is how the console tells you which half is missing. In watch mode, the default, it only logs.

// worker.js: in front of POST /signup on your zone
export default {
  async fetch(request, env, ctx) {
    const url = new URL(request.url);
    if (request.method !== 'POST' || url.pathname !== '/signup') {
      return fetch(request);
    }

    // Read the body once, then rebuild the request for the origin.
    const raw = await request.arrayBuffer();
    const fields = readFields(request.headers.get('Content-Type') || '', raw);
    const verdict = await checkVisitor(fields, env);

    if (env.MASKBREAK_MODE === 'enforce' && verdict?.decision === 'block') {
      return new Response(JSON.stringify({ error: 'Request declined' }), {
        status: 403,
        headers: { 'Content-Type': 'application/json' },
      });
    }
    // Watch mode, or anything short of a block in enforce mode: the origin
    // runs as before. A review is the origin's call (step up, not refuse).
    return fetch(new Request(request, { body: raw }));
  },
};

// Form posts carry monocle / sentinel_fp / sentinel_tz; JSON from
// Sentinel.collect() carries token / fingerprintEventId / tz.
function readFields(type, raw) {
  try {
    const text = new TextDecoder().decode(raw);
    if (type.includes('application/json')) {
      const body = JSON.parse(text);
      return body && typeof body === 'object' ? body : {};
    }
    if (type.includes('application/x-www-form-urlencoded')) {
      return Object.fromEntries(new URLSearchParams(text));
    }
  } catch (_) { /* unreadable body: send the check without evidence */ }
  return {};
}

async function checkVisitor(b, env) {
  let result = null;
  try {
    const res = await fetch('https://maskbreak.com/v1/evaluate', {
      method: 'POST',
      headers: {
        Authorization: `Bearer ${env.MASKBREAK_API_KEY}`,
        'Content-Type': 'application/json',
      },
      body: JSON.stringify({
        token: b.monocle || b.token || '',
        fingerprintEventId: b.sentinel_fp || b.fingerprintEventId || undefined,
        tz: b.sentinel_tz || b.tz || undefined,
        email: typeof b.email === 'string' ? b.email : undefined,
      }),
      // A deadline on every outbound call: no verdict beats a late one.
      signal: AbortSignal.timeout(3000),
    });
    if (res.ok) result = await res.json();
    else console.warn('[maskbreak] HTTP', res.status);   // 401: the key, 400: the body
  } catch (err) {
    console.warn('[maskbreak] unavailable:', err.name);   // fail open
  }
  // One line per check, in Workers Logs or wrangler tail. Never the key or token.
  console.log('[maskbreak]', JSON.stringify({
    mode: env.MASKBREAK_MODE || 'watch',
    decision: result ? result.decision : null,
    reasons: result ? result.reasons : null,
    device_evidence: result ? result.device_evidence : null,
    degraded: result ? !!result.degraded : null,
  }));
  return result;
}

Route it on the exact path, so the Worker never runs for your static files, and put the key in a secret. Worker code is not a browser bundle, but it is not a private server either: anyone with dashboard access can read the script, and it ends up in whatever repository you deploy from.

wrangler secret put MASKBREAK_API_KEY

MASKBREAK_MODE is an ordinary variable (vars in your Wrangler file), unset for now. Never const MASKBREAK_API_KEY = 'sk_live_...' at the top of the file, and never let the key reach the browser: a live key in client-side JavaScript is a key someone else is now using on your allowance.

Step 3: Submit your form once

Run the app on your computer or deploy it, open the page in an ordinary browser, wait a moment, and submit the form. The first check then appears in the Maskbreak console (if half of it did not arrive, the console says which half), and wrangler tail shows one [maskbreak] line. degraded: true means no network token arrived (the script was blocked, the class is missing, or the body was neither a form nor JSON); device_evidence: "not_sent" means no browser check id arrived; "ok" with degraded: false is a complete check.

After a few days of comparing those lines with the console's Events, set MASKBREAK_MODE to enforce and redeploy: the Worker then refuses a block and forwards everything else. For a stricter gate in front of a sensitive action, the Worker example on the integrations page forwards only a complete live allow in enforce mode.

Failing open at the edge is not optional

An origin that fails closed takes down one endpoint. An edge Worker that fails closed can take down everything on its route. Three rules worth holding to:

• Deadline everything. An abort signal on every outbound call. No verdict beats a late verdict.
• Catch broadly. Network error, abort, non-2xx, unparseable JSON: every one of them means "continue", not "throw".
• Have a removal plan. Delete the Workers route in the dashboard and the origin serves the path directly. A rollback you can do from a phone at 2am is worth more than a clever retry.

Also watch the Workers request allowance on your plan. Every request on the route counts, including the ones you pass straight through, and an account over its daily free allowance gets errors on the route unless the route is set to fail open. A busy route belongs on a paid plan.

Use waitUntil for anything you do not need an answer from

Logging a verdict to your own analytics endpoint should not add latency to the response. ctx.waitUntil keeps the Worker alive for the side effect after the response has already gone back:

ctx.waitUntil(
  fetch('https://your-collector.example/events', {
    method: 'POST',
    headers: { 'Content-Type': 'application/json' },
    body: JSON.stringify({ path: url.pathname, decision: verdict?.decision ?? null, asn: request.cf?.asn }),
  }).catch(() => {})       // never let telemetry break the request path
);

The short version

• The edge sees the network: IP, ASN, country, TLS. Use it for cheap triage before the origin.
• The edge never sees the device. Antidetect browsers, automation and emulators need the browser's evidence, sent with the form.
• Read monocle, sentinel_fp and sentinel_tz (or the collect() names) and send all three as token, fingerprintEventId and tz, every time.
• A datacenter ASN is a reason to add friction, not a reason to refuse outright.
• Deadline every outbound call and treat every failure as allow.
• Key in wrangler secret, read from env, never inline and never in the browser.
